Features:

• Vertical laminar flow, top-to-bottom return airflow model design to achieve "true laminar flow" in the core operating area;

• Integrate VHP dry sterilization technology to rapidly increase the concentration of sterilant, without condensation during the entire sterilization process, and reduce residual risk; the unique VHPS concentration control technology realizes dynamic variable control of hydrogen peroxide injection, preventing The concentration is too high or too low;

• The VHP sterilization process uses pressure control technology to reduce the risk of VHP penetrating the cell culture vessel;

• The temperature control function of VHP sterilization process and circulating air supply process can prevent the temperature in the chamber from being too high and reduce the impact on cell activity;

• Install an online dust particle and planktonic sampling system to dynamically monitor the Class A environment in the operating cabin;

• Movable docking incubator, which can realize the cultivation and medium exchange of multiple cell incubators. Each cell is cultured in an independent microenvironment to prevent cross-contamination and facilitate management;

• The automatic liquid exchange module greatly improves the liquid exchange efficiency, shortens the liquid exchange time and reduces labor costs;

• Realize modular design, on-site assembly, and can be installed in Class D clean room;

• Provide verification services: DQ, IQ, OQ, PQ, VHP penetration culture vessel confirmation.

Technical parameter:

Cleanliness class: class 100 class 100ISO 5ClassA

Video board: tempered glass 15mm

Filter level: HEPA≥99.995%, @0.3um

Operation cabin decontamination time: 2.5h

Illumination: 500Lx

Power supply: 380V 50Hz

Differential pressure: 20~80Pa adjustable

VHP sterilization effect: up to 6 log kills against Bacillus stearothermophilus

Dimensions: 5500×1205×2600mm (non-standard can be customized)

Cabin leakage rate: 0.5%/h

Cabin material: SUS316L stainless steel

1) Automatic incubator 37℃±0.2

2) Temperature resolution 0.1℃

3) Temperature fluctuation ±0.2℃

4) Humidity ≥95%

5) Carbon dioxide concentration 5%

6) Culture medium refrigeration temperature 2-8℃

7) Culture medium rewarming temperature 37℃

8) The medium exchange rate is 5min/Petri dish

9) The noise of the whole machine ≤65db
